Brigade Backeye®360 HD Camera System

The Brigade Backeye®360 BN360-360 High Definition Camera System – Part No. 5800 is an advanced 360° surround-view camera system designed to improve visibility and operator awareness on agricultural and farming machinery. Suitable for loaders, the system provides a comprehensive bird's-eye view around the machine, helping operators see areas that may otherwise be hidden by blind spots.

The Backeye®360 system combines multiple high-definition cameras to create a 360° panoramic view around the vehicle, making it easier for operators to monitor their surroundings when reversing, manoeuvring, loading, unloading and working in confined areas. This can be particularly valuable on busy farms, yards, livestock areas, grain stores and agricultural sites where people, vehicles and equipment may be working close to machinery.

Designed to improve visibility at low speeds, the system helps operators better judge distances and identify obstacles around the machine. The bird's-eye view can provide greater confidence when positioning a loader close to buildings, trailers, other machinery or materials.

Key Features

• Genuine Brigade Backeye®360 BN360-360 HD Camera System

• 360° high-definition surround view

• Bird's-eye camera perspective

• Multiple HD cameras provide comprehensive coverage around the machine

• Helps reduce blind spots

• Improves operator visibility when reversing and manoeuvring

• Ideal for loading and material handling applications

• Helps operators monitor obstacles around the machine

• Suitable for demanding agricultural environments

• Professional Brigade camera technology

Part number: 5800

Specification Overview

• 12-24Vdc

• AHD 1.0 (720p)

• 15 view modes

• 2 x video outputs

• Ultra-wide viewing angle (HxV): 182° x 118°

• Size (WxHxD)

  • ECU: 178 x 113 x 46mm

  • Camera: 161 x 50 x 44mm

• 5-year warranty




Contents

• 1 x ECU

• 4 x BN360-1000C cameras

• 1 x Video output cable to connect to SELECT range monitor

• 1 x set-up/view select button

• 1 x ECU power harness

• 1 x ECU interface/video input harness

Features

• 720p HD 360° image

• 15 different view modes (10 x landscape & 5 x portrait configurations)

  • Front & rear crossing-traffic

  • Customisable vehicle position

• 2 pre-defined configuration groups

• Configure & customise set up via PC calibration software

• Left, right, reverse & speed signal triggers

• Configurable on-screen parking markers

• Customisable overlay guidelines per camera view

• 2 x video outputs

• Ultra-wide viewing angle cameras: (HxV) 182° x 118°

• 1/4” CMOS sensor

• Video output: AHD 1.0 and NTSC

• 360 view and individual channels recordable on Brigade MDR recorders

Power

• Power consumption: 15 Watts

• Current: 1.22 Amps

Durability & Standards

• Mechanical vibration: 8.5G

• Mechanical shock: 51G

• Operating temperature: -30 to +75°C

• IP30 ECU

• CE marked

• E-Marked: UNECE R10 compliant

• FCC Approved

• IC Approved

• ISO 20653:2006

• ISO 13766-1:2018

Benefits for Agricultural & Farming Applications

• Improve operator visibility around loaders

• Help reduce blind spots when manoeuvring

• Make reversing and positioning machinery easier

• Improve awareness of people, vehicles and obstacles

• Help reduce the risk of low-speed collisions

• Protect valuable agricultural machinery and surrounding property

• Increase operator confidence when working in confined farmyards and busy agricultural environments

Suitable for

Loaders, Agricultural Loaders, Farm Machinery, Front Loaders, Wheel Loaders, Material Handling Equipment, Agricultural & Farming Vehicles

Note: Calibration kit is required for installation

Monitor and camera extension cables are NOT included
